SPECIFICATION:

D/A : Switchover CS4398
0dBFS signal output : 2.3V RMS (RCA),4.6V RMS (XLR)
Output Terminals : Gold plated Tube RCA unbalanced and gold plated XLR balanced
Frequency response : Less than +/- 0.1 dB deviation 10Hz-35kHz
Signal-to-noise ratio : More than 100dB (Vacuum tube XLR output)
Signal-to-noise ratio : More than 100dB (Vacuum tube RCA output)
Crosstalk : Less than -100dB
Distortion (XLR) : Less than 0.03%
Distortion (RCA) : Less than 0.03%
Intermodulation : Less than 0.03% (19kHz + 20kHz)
Vacuum tube : Sovtek 6H30 x1
Dimensions / Weight : 21cm x 43cm x 33cm (HxWxD) / 16kg(wood top panel)
Dimensions / Weight : 21cm x 43cm x 33cm (HxWxD) / 18kg(Metal top panel)
